SKU: B6SL5-20W
Designed for installations where space is limited, the BASE6 Mini Scene Light delivers powerful white area lighting...
$53.96
$53.96

RRP. Tax Included.

Find a Reseller

BASE6 Mini Scene Light

BASE6 Mini Scene Light

$53.96
BASE6 Mini Scene Light
BASE6 Mini Scene Light
BASE6 Mini Scene Light
BASE6 Mini Scene Light
BASE6 Mini Scene Light
BASE6 Mini Scene Light

BASE6 Mini Scene Light

$53.96
Description

Designed for installations where space is limited, the BASE6 Mini Scene Light delivers powerful white area lighting without compromising performance. Producing up to 1,800 raw lumens (1,335 effective lumens), it's ideal for canopies, service bodies, trailers, caravans, marine applications and 4WDs.

The integrated dimming function allows you to switch between 100% and 50% brightness, giving you the flexibility to maximise light output when working or reduce glare when less illumination is needed.

Built to handle harsh Australian conditions, the Mini Scene Light features a rugged aluminium housing, UV-resistant polycarbonate lens and an IP67/IP69K waterproof rating. It also includes interchangeable black and white covers, allowing you to match the light to your vehicle or installation.

Compact, durable and easy to install, the BASE6 Mini Scene Light is the perfect solution wherever reliable area lighting is required.

Features

  • High-output white LED scene light
  • Up to 1,800 raw lumens (1,335 effective lumens)
  • Two brightness levels:
    • 100% (1,800 raw lumens)
    • 50% (900 raw lumens)
  • Includes interchangeable Black & White covers
  • Wide 45° downward beam
  • Durable aluminium housing
  • UV-resistant polycarbonate lens
  • IP67 & IP69K waterproof and dustproof
  • ECE R10, CE & UKCA approved
  • Operates on 10–30V DC systems
  • Compact screw-mount design
  • 400mm pre-wired 3-core cable
  • Rubber mounting gasket included
  • 5 Year BASE6 Warranty

Specifications

Specification Details
Power 20W
Voltage 10–30V DC
Raw Light Output 1,800 lm / 900 lm
Effective Light Output 1,335 lm / 710 lm
Brightness Levels 100% / 50%
Beam Angle 45° Downward
Housing Material Aluminium
Lens Material UV-Resistant Polycarbonate
Lens Colour Clear
Covers Included Black & White Interchangeable Covers
Mounting Screw Mount
Cable 400mm 3-Core Cable
Gasket Rubber
IP Rating IP67 / IP69K
Approvals ECE R10, CE, UKCA
Dimensions 118 × 40 × 24mm
Operating Temperature -45°C to +65°C
Warranty 5 Years

Wiring

Wire Colour Function
Red Positive (+)
Black Negative (Ground)
Yellow Dimming Control (Switches between 100% and 50% brightness)
